Note: Monitor shown in photo above is sold separately.
The TASCAM Track Factory Project package is a complete, preconfigured, Studio-in-a-Box. It features a compact Intel NUC PC pre-loaded with Cakewalk® SONAR Professional Recording Software, and includes a TASCAM US-2x2 USB Audio Interface, as well as TASCAM TH-02 headphones, plus a TASCAM TM-80 Condenser Microphone.
Intel NUC Audio Optimized PC
A powerful Audio Production PC that features an Intel® i5 processor and Microsoft Windows® 10 Home edition. It comes fully optimized for digital multitrack recording and editing. It features hand-selected hardware components, expertly streamlined OS, and – most importantly – a completely pre-configured installation of Cakewalk SONAR Professional (see below) that all combine to deliver a truly Ready-to-Record solution.
Intel NUC PC Highlights:
- i5-5250U processor (3MB cache, 2.70GHz)
- 8GB RAM (DDR3 PC3-12800, 2x 4GB DIMM, 16GB max)
- 256GB solid state drive (M.2 format)
- Windows 10 Home operating system
- Monitor outs: Mini Display Port 1.2, MINI-HDMI 1.4a
- (4) USB 3.0 ports
- Built-in Gigabit Ethernet (LAN), Wi-Fi®, and Bluetooth® 4.2
- Tuned for Audio Performance by PCAudioLabs
- Includes keyboard and mouse
US-2x2 USB Audio Interface
Offering solid audio specifications, flexible connectivity, and an easy-to-use angled design, the US-2x2 is the ultimate 2 channel interface for home and project studios. To ensure sonic clarity, the US-2x2 features dual TASCAM Ultra-HDDA mic/line preamps, providing up to 57dB of gain with incredibly low noise, as well as NE5532 op-amps for rich, uncolored sound capture. The US-2x2 also features comprehensive connectivity options for easy integration of your existing gear.
US-2x2 USB Audio Interface Highlights:
- Two XLR/TRS (MIC/LINE) inputs with +48V phantom power
- Two Ultra-HDDA (High Definition Discrete Architecture) mic preamps
- Two TRS analog balanced outputs
- MIDI input and output (5 pin din)
- 8mW/ch headphone output
- NE5532 op-amps used at the audio input and output stages
- Up to 96kHz/24-bit recording
- USB 2.0 computer connection
- Two switchable high-impedance inputs
- Direct monitoring function for zero-latency monitoring
- Separate controls for line and headphone output volumes
TM-02 Monitor Headphones
These closed-back headphones are designed for both recording and mixing. These headphones provide excellent sound isolation and audio performance, with an exceptionally flat frequency response curve that spans 18Hz – 22kHz. Coupled with a foldable design and padded headband, the TASCAM TH-02 are the perfect recording headphones in the studio or on the road.
TASCAM TM-80 Condenser Microphone
A professional-quality medium-condenser microphone that's designed to capture both vocal and instrumental performances. To ensure that you are up and recording in seconds, the TM-80 microphone kit also includes an XLR cable, desktop stand, and shock-resistant suspension mount.
Cakewalk SONAR Professional Recording Software
Equipped with advanced technology, effortless workflow, and an interface that amplifies inspiration, Cakewalk's SONAR Professional features a full set of studio quality effects and virtual instruments, along with unlimited Audio, MIDI, and Instrument tracks. SONAR Professional comes with everything you'll need at your disposal to record, edit, and mix.
Cakewalk SONAR Professional Software Highlights:
- Unlimited Audio, MIDI, and Instrument Tracks
- 56 professional mixing and mastering effects
- 19 virtual instruments
- Analog-style ProChannel Strip
- Melodyne Essential Pitch Correction
- Addictive Drums 2 Solo Edition
