$311.00 $249.00

Excellent for touring professionals, the Beta 87C premium vocal microphone delivers studio-grade performance and a smooth, extended high-end frequency response in a cardioid condenser design.

The microphone adds warmth to the frequency response and creates an ideal environment for in ear personal monitoring. And its highly consistent cardioid pattern offers excellent rear rejection.

Vocalists who use earphone monitor systems such as Shure PSM™ will appreciate how effectively the BETA 87C rejects ambient sound from the rear of the microphone.

Transducer Type
Condenser (electret bias)

Frequency Response
50 to 20,000 Hz

Polar Pattern
Cardioid

Output Impedance
Rated at 150 ohms (100 Ohms actual +/- 20%)
Recommended minimum load impedance: 800 ohms

Sensitivity (at 1,000 Hz)
Open Circuit Voltage: -51 dBV/Pa (2 mV)
(1 Pa = 94 dB SPL)>

Output Clipping Level
1000 Ohm Load at 1,000 Hz: -6 dBV (0.5 V)

Maximum SPL
139 dB at 1,000 Hz (0.25% THD, 1000 Ohm load)

Self-Noise
22 dB typical, A-weighted
24 dB typical, weighted per DIN 45 405
(equivalent sound pressure level; measured with true rms voltmeter)

Dynamic Range
117 dB (maximum SPL to A-weighted noise level)

Hum Sensitivity
-5 dB equivalent SPL, maximum, in a 1 mOe field (60 Hz)

Signal-to-Noise Ratio
72 dB at 94 dB SPL (IEC 651)*
*S/N ratio is difference between 94 dB SPL and equivalent SPL of self-noise A-weighted.

Polarity
Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of the output connector.

Power
Phantom Supply Requirement: 11 to 52 Vdc, positive at both pins 2 and 3
Current Drain: 1.0 to 1.2 mA

Connector
Three-pin (XLR) professional audio

Case
Aluminum construction with painted blue metallic finish, and hardened steel grille with nickel satin chrome plating

Net Weight
Net: 207 grams (7.6 oz)
Packaged: 565 grams (1.24 lbs)

Environmental Conditions
Operating: -18 degrees to 60 degrees C (0 degrees to 135 degrees F)(relative humidity <90%)
Storage: -29 degrees to 74 degrees C (-20 degrees to 165 degrees F) (relative humidity <80%)
